Making a cargo area
4-14 Seat and restraint systems
6. Fold forward the seat belt buckle.
7. Pull up the lever (D), then fold the seat-
back forward.
1. Raise the seatback until it locks securely
into place.
2. While lifting the seat belt buckle (A), gen-
tly lower the seat cushion. Make sure that
there is a hook (B) at the position shown
in the illustration.
Do not allow any person to get on the plastic
cover (C), and do not place luggage on it.
Doing so could damage the plastic cover.
Do not allow any person to sit on the flipped
seat cushion, and do not place luggage on it.
The seat’s mounting fittings could bend
under the weight, making it impossible for
the seat cushion to be secured when it returns
to the original position.
If the seatback cannot be folded, follow the
steps below.
1. Raise the seatback once until it locks.
2. Pull the strap again.
3. Pull up the lever, then fold the seatback
forward.
To return
BK0223400US.book 14 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
