Seat belts
4-20 Seat and restraint systems
5. To release the belt, press the button on the
buckle and allow the belt to retract.
If the belt does not retract smoothly, pull it
out and check for kinks or twists in the
webbing. Then make sure it remains
untwisted as it retracts.
N00409900035
The center seat belt for the second row can be
detached to fold the left side second row seat.
This seat belt must be worn correctly as illus-
trated.
1. Pull out the detachable anchor plate (C)
from the storage pocket on seat back
cushion.
2. Pull out the small latch plate (A) and then
pull out the latch plate (B) by tilting it as
shown in the illustration.
Be sure the lap belt portion fits snugly and
is worn as low as possible across the hips,
not around the waist. Failure to follow this
instruction will increase the risk of serious
injury or death in the event of an accident.
Be sure the seat belt webbing is not
twisted when worn. Twisted webbing may
adversely affect seat belt performance.
Detachable center seat belt for
second row
Never detach the center seat belt except
when the left side seat back in the second
row is folded. Using the center seat belt
with the detachable anchor unlatched
increases the risk of serious injury or
death in an accident. Make sure the small
latch plate (A) is properly latched to the
detachable anchor before the center seat
belt is used.
To attach
Pulling out the latch plate by force may dam-
age the headliner.
BK0223400US.book 20 ページ ２０１５年２月１３日 金曜日 午後１２時１５分
