Mitsubishi ASX 2019

Ventilators
1- Centre ventilators
2- Side ventilators
NOTE
l
Do not place beverages on top of the instru-
ment panel.
If they splash into the air conditioning venti-
lators, they could damage the system.
Air flow and direction adjust-
ments
Centre ventilators
Move the knob (A) to adjust the air flow di-
rection.
To close the ventilator, fully move the knob
(A) to the inner side.
1- Close
2- Open
Side ventilators
Move the knob (A) to adjust the air flow di-
rection.
To close the ventilator, fully move the knob
(A) to the outer side.
Left Right
1- Close
2- Open
NOTE
l
On vehicles with air conditioning, the cool
air from the ventilators may appear as a
mist.
This is due to moist air being suddenly
cooled by the air conditioning. This will
clear after a few moments.
l
Be careful not to spill drinks, etc., into the
ventilators.
Doing so might cause the air conditioning
not to function normally.
Ventilators
7-02
OGAE19E1
For pleasant driving
7
