Front fog lamps*
1. Remove the clip (A).
2. Insert a straight blade (or minus) screw-
driver with a cloth over its tip into the
fog lamp cover (B) and pry gently to re-
move it.
3. Remove the screws (C) and remove the
lamp unit.
NOTE
l
Except for vehicles equipped with daytime
running lamps, when unfastening the screws,
be careful not to move the beam position ad-
justment screw (D).
4. While holding down the tab (E), pull out
the socket (F).
5. Turn the bulb (G) anticlockwise to re-
move it.
6. To install the bulb, perform the removal
steps in reverse.
Replacement of lamp bulbs
10-29
OGAE19E1
Maintenance
10
