Mitsubishi ASX 2019

5- Headlamps, low beam Halogen: 55 W
(H11)
High intensity discharge
*2
: 35 W (D2S)
5 W (W5W)
6-
Position lamps: (Type 1)
*1
5 W (W5W)
7-
Side turn-signal lamps (on fender)
*1
,
*2
:
5 W
8- Side turn-signal lamps (on outside rear-
view mirror)
*1
Codes in parentheses indicate bulb
types.
WARNING
l
Check with a MITSUBISHI MOTORS
Authorized Service Point when it is neces-
sary to repair a high intensity discharge
headlamp or to replace the bulb.
High voltage is generated in the high in-
tensity discharge headlamp bulb and elec-
trodes, which may cause a severe shock
when the bulb and connector are removed
or disconnected.
*2
Have the lamps bulbs replaced at a
MITSUBISHI MOTORS Authorized
Service Point.
*1
If so equipped
NOTE
l
An LED, not a bulb, is used in the daytime
running lamp/position lamp (Type 2) and the
side turn-signal lamp (on the outside rear-
view mirror).
Contact a MITSUBISHI MOTORS Author-
ized Service Point when there is a need for
repair or replacement.
l
For the side turn-signal lamp (on fender), it
is not possible to repair or replace just the
bulb.
Contact a MITSUBISHI MOTORS Author-
ized Service Point when there is a need for
repair or replacement.
Rear
9- High-mounted stop lamp
10- Licence plate lamps: 5 W (W5W)
11- Rear fog lamp
12- Reversing lamps: 16 W (W16W)
13- Rear turn-signal lamps: 21 W (W21W)
14- Stop and tail lamps
Codes in parentheses indicate bulb
types.
NOTE
l
An LED, not a bulb, is used in the stop and
tail lamp, the high-mounted stop lamp and
the rear fog lamp.
Contact a MITSUBISHI MOTORS Author-
ized Service Point when there is a need for
repair or replacement.
Inside
1-
Room lamp (rear)
*
: 8 W
2-
Vanity mirror lamps
*
: 2 W
3- Room lamp (front) & map lamps: 8 W
4- Luggage room lamp: 5 W
5- Centre console down lamp
6- Glove box lamp: 1.4 W
*
If so equipped
Replacement of lamp bulbs
10-25
OGAE19E1
Maintenance
10
