12-38 Simple inspection and service
If the warning lamp lights up, there is water in
the fuel filter in an amount exceeding the limit.
Drain the water as follows:
1. Prepare a receiver for water.
2. Disconnect the connector on the sensor , then
turn the sensor in the direction of the arrow to
loosen it; the water will flow from the pipe at the
end of the sensor.
Operating priming pump helps quicken the
draining (press the pump handle approximately
7 times).
3. When fuel begins to flow out, close the drain
port by tightening the plug in the direction of the
arrow .
Connect the connector.
4. Bleed the fuel system. P. 13-23
5. Start the engine and check that fuel does not
leak.
Draining water from fuel filter
WARNING
• Fuel is highly flammable and should be
kept away from hot objects and open
flames owing to the risk of fire or explo-
sion. Wipe up any spilt fuel.
• Keep cigarettes and other sources of heat
away from the vehicle while draining water
from the fuel filter. They are dangerous
because they could set fire to the fuel.
• Be careful not to injure yourself on the
edges of nearby components while drain-
ing water from the fuel filter.
Tightening torque
5 ± 1 N·m (3.7 ± 0.7 ft.lbs.,
0.5 ± 0.1 kgf·m)
WARNING
• The drain contains not only water but also
fuel.
Be sure to wipe clean the surfaces around
the fuel filter to remove all splashed fuel.
Fuel remaining on the surfaces could
cause a fire.
• Make sure fuel does not leak from the filter
or from related parts. Any fuel leakage
could cause a fire.
Z12062
FEFG.book Page 38 Thursday, March 10, 2005 7:30 PM
