12-68 Simple inspection and service
2 Dashboard air filter
•
Removal
1. Remove the four screws that retain the bot-
tom of the lower center panel and the bottom
of the lower panel .
2. Release the tabs on the lower panel and
lower center panel, then remove the lower
panel.
3. Remove the screw that retains the bottom of
the tray .
4. Open the glove compartment, then remove the
two screws .
5. Remove the three sets of plugs and screws ,
then remove the tray.
6. Withdraw the air filter .
Z11171
Z11620
FEFG.book Page 68 Thursday, March 10, 2005 7:30 PM
