12-74 Simple inspection and service
2.8 Removing floor mat for cleaning
When removing the floor mat for cleaning, you must
raise the accelerator pedal by using the following
method.
1. Hold the hooked end of stopper with pliers
and pull the stopper toward the front of the vehi-
cle while twisting the hooked end through
approximately 15 degrees to disengage the end
from the pedal.
2. To return the pedal to the original state, fit accel-
erator arm inside the stopper, and force the
hooked end of the stopper in the hole of the
pedal.
3. Check to ensure that the stopper does not dis-
engage.
CAUTION
Do not use force to disengage the stopper from
the pedal. Always pull it while twisting.
After cleaning the floor mat, dry the felt backing
before putting the mat back on the floor. When fit-
ting the floor mat back in the vehicle, make sure it
does not interfere with the accelerator pedal and
other moving parts.
Z09336
Z12176
15°
