14-2 Service data
1 Quantities of lubricants/hydraulic fluids
liters (qts)
CAUTION
The indicated oil and fluid quantities should be used only as a guide at the time of replacement. To
ensure correct oil and fluid levels, use the oil level gauge, inspection plug holes, and level lines as
appropriate.
Recommended lubricants/hydraulic fluids and quantities
Item Quantity
Engine
Oil pan
FE Approx. 9 (9.5)
FG Approx. 10 (11)
Oil filter Approx. 1 (1.1)
Manual transmission
5-speed Approx. 3.6 (3.8)
6-speed Approx. 4.4 (4.6)
Automatic
transmission
Total quantity Approx. 12.9 (14)
Replacement quantity Approx. 6.4 (6.8)
Transfer <FG> Approx. 3.1 (3.3)
Axle housing
FE Approx. 4.5 (4.8)
FG
Front axle Approx. 3.0 (3.2)
Rear axle Approx. 4.5 (4.8)
Power steering
FE
Models other than FE85 Approx. 1.9 (2.0)
FE85 Approx. 2.3 (2.4)
FG Approx. 1.8 (1.9)
Brake fluid (for both brakes and clutch) As required
FEFG.book Page 2 Thursday, March 10, 2005 7:30 PM
