14-4 Service data
Service data
Description Standard value
Engine idling speed 625 to 675 rpm
Belt tension [amount of deflection
under a 98 N (22 lbs., 10 kgf) pres-
sure at the point midway between pul-
leys]
Fan belt
Vehicles without air
conditioner
New belt (when installed):
9 to 11 mm
(0.35 to 0.43 in.)
Used belt (when inspected
or reinstalled):
11 to 13 mm
(0.43 to 0.51 in.)
Vehicles with air
conditioner
New belt (when installed):
7 to 9 mm
(0.28 to 0.35 in.)
Used belt (when inspected
or reinstalled):
10 to 11 mm
(0.39 to 0.43 in.)
Coolant quantity
Approx. 14.4 liters
(15.2 qts)
Clutch pedal play (at center of pedal pad)
0.2 to 4 mm
(0.0079 to 0.16 in.)
Brake pedal play
0.1 to 3 mm
(0.0039 to 0.12 in.)
Fully depressed brake pedal to floor clearance 20 mm (0.79 in.) or more
Parking brake lever stroke 7 to 9 notches
Steering wheel play (as measured on the periphery of steering wheel)
5 to 50 mm
(0.2 to 1.97 in.)
Tire tread groove depth 1.6 mm (0.06 in.) or more
Wheel nut tightening torque
440 to 540 N·m
(325 to 398 ft.lbs.,
45 to 55 kgf·m)
Tire inflation pressure
FE84
LT215/85R16-10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
FE85
215/75R17.5
124/123L
(Load Range F)
690 kPa
(100 psi, 7.0 kgf/cm
2
)
FG
LT235/85R16-10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
