6-2 Instruments and warning lamps
Speedometer
Tachometer
Fuel gauge
Warning/indicator lamps
DEF level indicator
Multi-information display
The speedometer indicates vehicle speed in miles
or kilometers per hour.
• The tachometer indicates engine speed in revo-
lutions per minute.
• The green zone indicates the engine speed
that is a rough guide for economic operation.
• If the needle enters the red zone , the engine
is overrevved. Reduce the vehicle speed suffi-
ciently during downhill driving or downshifting to
keep the needle from entering this zone.
P. 7-12
CAUTION
The term “overrev” refers to rotation of the
engine at an RPM exceeding the maximum limit.
This occurs when the engine is driven by the
wheels during downhill driving or downshifting.
Persistent overrevving can lead to an engine
breakdown.
Arrangement of instruments and
warning lamps
Speedometer
Tachometer
Z21356
Z21357
Z20962
FE_FG.book Page 2 Tuesday, February 8, 2011 4:00 PM
