13-22 Useful advice for emergencies

6. Remove the screws of the garnish , then

remove the garnish toward the outside of the

vehicle.

NOTE:

Do not remove the end rubber piece from the

garnish.

7. Remove the headlamp’s bolts .

8. Raise the headlamp slightly to remove the tabs

from the holes , then pull it out toward you.

Z21431

Z22067

Z21750

Z22088
