7 Buffer Memory
7.2 Buffer memory details
38
FX3U-64CCL User's Manual
7.2.6 [BFM#27] Set value of host station number
This buffer memory address stores the set value of the host station number and is determined when the
64CCL is started.
The stored value does not change even if the setting is changed after startup.
7.2.7 [BFM#28] Number of occupied stations, expanded cyclic set value
This buffer memory address stores the value set by the rotary switch and is determined when the 64CCL is
started.
The stored value does not change even if the setting is changed after startup.
BFM#27 Set value of host station number
Setting
(decimal)
Description
1 to 64 Host station number
0,65 to 99
Setting error
The set value remains stored even if a setting error occurs.
BFM#28 Number of occupation stations, expanded cyclic set value
Setting
(hexadecimal)
Number of occupied stations Expanded cyclic setting
01 station Single
1 2 stations Single
2 3 stations Single
3 4 stations Single
4 1 station Double
5 2 stations Double
6 3 stations Double
7 4 stations Double
8 1 station Quadruple
9 2 stations Quadruple
A, B Setting error Setting error
C 1 station Octuple
D to F Setting error Setting error
