7 Buffer Memory
7.2 Buffer memory details
48
FX3U-64CCL User's Manual
7.2.15 [BFM#176 to 207] Remote register RWw
These remote register (RWw) buffer memory addresses store the word information received from the
master station.
Read these buffer memory addresses using the FROM instruction (or direct buffer memory specification)
to use the stored word information.
Caution
• When the TO instruction (or direct buffer memory specification) is executed, writing is invalid. When the
FROM instruction (or direct buffer memory specification) is executed for reading from an area without
assigned link points, the reading operation results in "0" being read.
: Applicable -: With no allocation
BFM
No.
Remote
register
number
Number of occupied stations
Occupies 1 station Occupies 2 stations Occupies 3 stations Occupies 4 stations
Expanded cyclic setting
Single Double
Quadru
ple
Octuple Single Double
Quadru
ple
Single Double Single Double
#176 RWw00
#177 RWw01
#178 RWw02
#179 RWw03
#180 RWw04 -
#181 RWw05 -
#182 RWw06 -
#183 RWw07 -
#184 RWw08 - - -
#185 RWw09 - - -
#186 RWw0A - - -
#187 RWw0B - - -
#188 RWw0C - - - -
#189 RWw0D - - - -
#190 RWw0E - - - -
#191 RWw0F - - - -
#192 RWw10 - - - - - - -
#193 RWw11 - - - - - - -
#194 RWw12 - - - - - - -
#195 RWw13 - - - - - - -
#196 RWw14 - - - - - - -
#197 RWw15 - - - - - - -
#198 RWw16 - - - - - - -
#199 RWw17 - - - - - - -
#200 RWw18 - - - - - - - -
#201 RWw19 - - - - - - - -
#202 RWw1A - - - - - - - -
#203 RWw1B - - - - - - - -
#204 RWw1C - - - - - - - -
#205 RWw1D - - - - - - - -
#206 RWw1E - - - - - - - -
#207 RWw1F - - - - - - - -
Buffer memory points 4 8 16 32 8 16 32 12 24 16 32
