Mitsubishi HC3800 User Manual

EN-29
Menu operation (continued)
4. SIGNAL menu 5. USER menu
R G B
R G B
SIGNAL
HORIZ. POSITION 0
VERT. POSITION 0
TRACKING 0
COMPUTER
INPUT
AUTO
FINE SYNC. 0
USER
opt.
OK
ON
HOLD
100%
OVER SCAN
AV MEMORY 1
CLAMP
POSITION
USER
1
CLAMP WIDTH 1
LPF OFF
SHUTTER(U) 0
SHUTTER(L) 0
VERT. SYNC AUTO
?
SHUTTER(LS) 0
SHUTTER(RS) 0
4. SIGNAL menu
ITEM SETTING FUNCTION
HORIZ. POSITION 0 - 999 Use to adjust the horizontal position of the projected image.
VERT. POSITION 0 - 999 Use to adjust the vertical position of the projected image.
FINE SYNC. 0 - 31 Use to eliminate flickering or blur, if it appears, while viewing the projected
image.
TRACKING 0 - 9999 Use to eliminate vertical wide stripes, if it appears, while viewing the projected
image.
COMPUTER INPUT AUTO The proper setting is automatically selected.
RGB Select this option when connecting the projector to high definition video
equipment having R, G, and B output terminals.
YC
B
C
R
/ YP
B
P
R
Select this option when connecting the projector to a DVD player or other
device having Y, C
B
, and C
R
(or Y, P
B
, and P
R
) component video output
terminals.
OVER SCAN 100 - 90% Use to adjust the display area of the projected image when playing LD and
DVD discs.
HOLD OFF / ON Use to adjust the image when flagging occurs near the top of the screen.
Though horizontal strips may appear on the enlarged projected image, such symptom is not a malfunction.
When you change the horizontal or vertical position to a large extent, noise may appear.
The adjustable range of the vertical position varies depending on the type of the input signal. Though the image
may stay in the same position even when the setting value is changed, such symptom is not a malfunction.
If you increase the OVER SCAN setting when viewing video signals, noise may appear on the screen. In this case,
decrease the OVER SCAN setting.
5. USER menu
ITEM SETTING FUNCTION
CLAMP POSITION 1 - 255 Use to correct solid white or solid black in the projected image.
CLAMP WIDTH 1 - 63 Use to correct solid black in the projected image.
VERT. SYNC AUTO / OFF Use to adjust the image when its motion doesn’t run smoothly. Select AUTO
for normal use.
LPF ON / OFF Use to select whether or not to enable the LPF.
SHUTTER(U) 0 - 32 Use to display the black bar on the top part of the image.
SHUTTER(L) 0 - 32 Use to display the black bar on the bottom part of the image.
SHUTTER(LS) 0 - 95 Use to display the black bar on the left half of the image.
SHUTTER(RS) 0 - 95 Use to display the black bar on the right half of the image.
•
•
•
•

Mitsubishi HC3800 Specifications

General

Native aspect ratio	-
Projection distance	- m
Vertical scan range	50 - 85 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	4000:1
Screen size compatibility	50 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-15 - 15 °
Focus	Manual
Focal length range	20.6 - 30.1 mm
Lamp power	230 W
Light source type	Lamp
Lamp power (economic mode)	190 W
Service life of light source	5000 h
Noise level	31 dB
Plug and Play	Yes
Dot clock scanning frequency	170 MHz
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Built-in speaker(s)	No
Audio (L/R) in	2
Serial interface type	RS-232
USB 2.0 ports quantity	0
S-Video inputs quantity	1
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	340 W
Placement	Desktop
Product type	Standard throw projector
Product color	Black

Weight and Dimensions

Depth	270 mm
Width	345 mm
Height	129 mm
Weight	3500 g
