3-174
Features and controls
3
CAUTION
!
● The rear-view camera uses a wide-angle lens. As a
result, images and distances shown on the screen are
not exact.
● Actual distance may be different from distance indi-
cated by the lines on the screen, depending on the
loading condition of the vehicle and road surface
condition.
The reference lines for distance and vehicle width
are based on a level, flat road surface. In the follow-
ing cases, objects shown on the screen will appear to
be farther off than they actually are.
• When the rear of the vehicle is weighed down with
the weight of passengers and luggage in the vehi-
cle. (Case 1)
• When there is an upward slope at the back.
(Case 2)
A- Actual objects
B- Objects shown on the screen
Case 1
Case 2
A- Actual objects
B- Objects shown on the screen
