Fog lamp switch
E00506700034
Front fog lamp switch
E00508300366
The front fog lamps can be operated while the head-
lamps or tail lamps are on. Turn the knob in the
“ON” direction to turn on the front fog lamps. An
indication lamp in the instrument cluster will also
come on. Turn the knob in the “OFF” direction to
turn off the front fog lamps. The knob will automat-
ically return to its original position when you re-
lease it.
NOTE
l
The
front fog lamps are automatically turned
off when the headlamps or tail lamps are
turned off. To turn the front fog lamps on
again, turn the knob in the “ON” direction af-
ter turning on the headlamps or tail lamps.
l
Do not use fog lamps except in conditions of
fog, otherwise excessive lamp glare may tem-
porarily blind oncoming vehicle drivers.
l
In
case of vehicles with Daytime Running
Lamp, the front fog lamps can be operated
even if the lamp switch is set to the “OFF”
position.
Rear fog lamp switch
E00508400338
The rear fog lamp can be operated when the head-
lamps or front fog lamps turn on.
An
indication lamp in the instrument cluster comes
on when the rear fog lamp is turned on.
Turn the knob once in the “ON” direction to turn
on the front fog lamps. Turn the knob once more in
the “ON” direction to turn on the rear fog lamp. To
turn the rear fog lamp off, turn the knob once in the
“OFF” direction. Turn the knob once more in the
“OFF” direction to turn off the front fog lamps.
The knob will automatically return to its original po-
sition when you release it.
NOTE
l
The
rear fog lamp is automatically turned off
when the headlamps or front fog lamps are
turned off.
l
To
turn the rear fog lamp on again, turn the
knob twice in the “ON” direction after turn-
ing on the headlamps.
l
In case of vehicles with Daytime Running
Lamp, the rear fog lamp can be operated
even if the lamp switch is set to the “OFF”
position.
Instruments and controls
3-44
3
