Position lamps
E01003700501
1. To
create enough work space, turn the steer-
ing wheel all the way in the direction oppo-
site to the side you wish to replace.
2. Remove the clips (A), clip (B) and screw (C)
to turn up the cover (D).
3. Turn the socket (E) anticlockwise to remove
it.
4. Pull the bulb out of the socket.
5. To
install the bulb, perform the removal
steps in reverse.
Front turn-signal lamps
E01003801017
1. Remove
the clips (A) and clips (B), then re-
move the duct (C) and the upper cover (D).
2. Remove
the entire socket and bulb assembly
(E) by turning it anticlockwise.
*: Front of the vehicle
Maintenance
8-24
8
