3. Remove the bulb by pulling it out.
4. To
install the bulb, perform the removal
steps in reverse.
Front fog lamps
E01004000859
1. Remove
the clips (A) and clips (B), then turn
up the cover (C).
2. While
holding down the tab (D), pull out the
socket (E).
3. Turn the bulb (F) anticlockwise to remove it.
4. To
install the bulb, perform the removal
steps in reverse.
CAUTION
l
Handle
halogen lamp bulbs with care.
The gas inside halogen lamp bulbs is high-
ly pressurized, so dropping, knocking, or
scratching a halogen lamp bulb can cause
it to shatter.
l
Never hold the halogen lamp bulb with a
bare hand, dirty glove, etc.
The oil from your hand could cause the
bulb to break the next time the fog lamps
are used. If the glass surface is dirty, it
must be cleaned with alcohol, paint thin-
ner, etc., and refit it after drying thorough-
ly.
Maintenance
8-25
8
