6-14
For emergencies
6
3. Rotate the jack by hand until the flange portion (B) fits in
the groove (C) at the top of the jack.
4. Insert the bar (D) into the wheel nut wrench (E). Then put
the end of the bar into the shaft’s jack end, as shown in the
illustration.
Slowly rotate the wheel nut wrench until the tire is raised
slightly off the ground surface.
WARNING
!
● Stop jacking up the vehicle as soon as the tire is
raised off the ground. It is dangerous to raise the
vehicle any higher.
● Never get under the vehicle or put any portion of
your body under the vehicle while it is supported by
the jack.
● Do not bump the raised vehicle or leave it sitting on
the jack for a long time. Both are very dangerous.
● Do not use a jack except the one that came with your
vehicle.
BK0102103US.book 14 ページ ２００９年１０月２６日 月曜日 午後１時３８分
