Rear shelf panel (if so equipped)
Features and controls 5-109
There are bottle holders located on the front
doors.
N00528200096
1. Insert the concave portion (A) on the
underside of the rear shelf panel into the
inside protruding portion (B) of the rear
pillar.
2. Hang the strap (C) of the rear shelf panel
on the hook (D).
Follow this procedure in reverse to remove.
N00574700014
Convenience hook is located on the seatback
of the passenger’s seat.
Do not store cup or drink can in the bottle
holder.
Make sure all lids are tightly closed when
storing beverages that are in plastic bottles,
etc.
Some beverages may not be stored, depend-
ing on the size and shape of the plastic bot-
tles, etc.
Rear shelf panel (if so equipped)
Do not place luggage or other items on the
rear shelf panel. Any items on the rear shelf
panel would obstruct your rearward view,
and they could fly forward and cause injuries
or other mishap in the event of hard braking.
To install
Lightly push the rear shelf panel to make
sure that the concave portion (A) is set
firmly in the protruding portion (B) of the
liftgate. If the rear shelf panel is not securely
locked in place, it could unhook while driv-
ing and cause injuries.
To remove
Convenience hook
