The engine serial number is stamped on the
cylinder block as shown in the illustration.
N01148100616
The tire and loading information placard is
located on the driver’s door sill.
N01148200242
The certification label is located on the
driver’s door sill.
N01147501577
N01147600917
Engine serial number
*- Front of the vehicle
Tire and loading information
placard
Certification label
Vehicle dimensions
Overall length 148.8 in (3,780 mm)
Overall width 65.6 in (1,665 mm)
Overall height 59.4 in (1,510 mm)
Wheel base 96.5 in (2,450 mm)
Vehicle weights
Item M/T CVT
Gross vehicle weight rating 2,910 lb (1,320 kg) 3,020 lb (1,370 kg)
