Tire repair kit (if so equipped)
For emergencies 8-9
12. Pull out the compressor’s power cord (K),
insert the plug on the cord into the 12 V
power outlet (L), and then turn the igni-
tion switch or the operation mode to the
ACC position. (Refer to “12V power out-
let” on page 5-106.)
Turn ON the compressor switch (M) and
inject all of the tire sealant and inflate the
tire to the specified pressure. (Refer to
“Tire inflation pressures” on page 9-14.)
If there is a gap between the tire and
wheel, push the tread area toward the cen-
ter of the wheel to close the gap before
running the compressor.
13. Affix the speed restriction sticker (N) to
the three-diamond mark on the steering
wheel.
If the bottle hose is not attached securely, the
tire sealant will leak out from the tire valve
and the tire may not inflate to the specified
pressure.
Do not place your hand or fingers between
the tire and wheel while inflating the tire.
Your hand or fingers may become caught
between the tire and wheel.
The supplied compressor is designed only
for inflation of your vehicle tires.
The compressor is designed to run on a vehi-
cle’s 12 V power supply. Do not connect it to
any other power source.
The compressor is not waterproof. If you use
it in rain, make sure water does not get on it.
Any sand or dust sucked into the compressor
could make the compressor break down. Do
not place the compressor directly on any
sandy or dusty surface when using it.
Do not disassemble or modify the compres-
sor. Also, do not subject the air pressure
gauge to shock. It could malfunction.
Do not affix the sticker anywhere except the
specified position on the pad of the steering
wheel. Affixing the sticker in an incorrect
position could prevent the SRS airbag from
deploying properly.
