7. Install the wheel nuts with their tapered
ends facing inward, then tighten by hand
until the wheel is no longer loose.
8. Lower the vehicle slowly until the tire
touches the ground, by rotating the wheel
nut wrench counterclockwise.
9. Tighten the nuts in the order shown in the
illustration until each nut has been tight-
ened to the torque listed here.
65 to 80 ft-lb (88 to 108 N•m)
10. Lower the jack all the way and remove it.
11. Check the tire inflation pressure. The rec-
ommended tire pressure for your vehicle
is listed on the tire and loading informa-
tion placard attached to the driver’s door
sill as shown in the illustration. Refer to
“Tire inflation pressures” on page 9-14.
Never use your foot or a pipe extension to
apply added force to the wheel nut wrench
when tightening the wheel nuts. If you do so,
you can over-tighten the wheel nuts and
damage the wheel, wheel nuts and hub bolts.
