Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
ENGLISH
FUEL FILTER MAINTENANCE
180 / 195
MAINTENANCE
50 FUEL FILTER
50.1 Fuel filter with [AIR] valve
Close the fuel filter valve. Loosen the ring nut and take
out the element for cleaning or replacement.
50.2 Cartridge (air vent screw) type
fuel filter
Replace the filter as an assembly if water and sediment
have been accumulated in it.
Figure 264 Fuel filter with [AIR] valve
Valve lever
Element
Ring nut
Figure 265 Cartridge type fuel filter

Mitsubishi S4L Specifications

General

Aspiration	Naturally Aspirated
Fuel Type	Diesel
Cooling System	Water-cooled
Starting System	Electric Starter
Lubrication System	Forced Lubrication
Engine Type	4-stroke, vertical, water-cooled, direct injection diesel engine
Max Power Output	48.5 kW (65 hp) at 2200 rpm
