189 / 195
Service Manual Mitsubishi SL-Series diesel engines
Version 08/2004
SPECIFICATIONS
ENGLISH
SERVICE DATA
55.5 Cooling system (standard)
Unit: mm (in.)
55.6 Electrical system
Unit: mm (in.)
Item Standard Limit Correction-Remarks
Thermostat
Temperature at which valve
starts opening
82 ± 1.5°C
(180 ± 2.7°F)
—
Replace.
Temperature at which valve lift
is more than 8 mm (0.3 in.)
95°C (203°F) —
Thermo-
switch
Temperature at which switch is
turned ON
111 ± 3.5°C
(232 ± 6.3°F)
—
Replace.
Resistance at oil temperature
of 120°C (284°F)
30 mΩ maximum —
Resistance
in
thermounit
At 50°C (122°F) 80 ± 10 Ω —
Replace.At 80°C (176°F) 29.5 ± 2.5 Ω —
At 120°C (248°F) 10 ± 0.3 Ω —
Deflection of fan belt under 10 kgf (22 lbf)
[98 N] force applied midway between
alternator pulley and crankshaft pulley
10 to 12
(0.4 to 0.5)
— Replace.
Item Standard Limit Correction-Remarks
Starter
Pinion clearance
0.5 to 2.0
(0.020 to 0.079)
— Adjust with packing.
No-load
charac-
teristics
S3L/S3L2 S4L/S4L2
Test.
Terminal voltage 11.5 V 11 V —
Current draw
100 A
maximum
130 A
maximum
—
rpm
3 000
minimum
3 600
minimum
—
Brush length — Wear limit line Replace.
Brush spring tension
3.0 kgf
(6.6 lbf)
[29.4 N]
1.8 kgf
(4.0 lbf)
[17.7 N]
Replace.
Runout of commutator 0.03 (0.001 2) 0.10 (0.003 9) Repair or replace.
Diameter of commutator 32 (1.26) 31 (1.22) Replace.
Undercut of mica 0.5 (0.020) 0.2 (0.008) Repair.
To Next Page
