Mitsubishi S6R Series

1-11
Chapter 1 GENERAL
Engine Front View
Engine Rear View
Tension pulley
Thermostat case
Oil pan
Water pump
Damper
Note: Configuration varies depending on the destination and specifications.
S6R-Z3MPTAW
Engine coolant outlet
Flywheel
Timing gear case
Silencer
S6R-Z3MPTAW
Note: Configuration varies depending on
the destination and specifications.
Engine oil drain port
Rotation directionRotation directionRotation direction
