3-5
Chapter 3 SERVICE TOOLS
Basic engine Cylinder liner remover 37591-04100 Cylinder liner - remove
Applicable cylinder liner inner diam:
ø170 mm [6.69 in.]
Cam bushing tool
assembly
37591-08020 Cam bushing installation/removal
Jack bolt 64362-68500 Water pump plate - remove
Valve spring pusher 33591-04500 Valve spring - install/remove
Valve lapper Suction cup diam:
ø35 mm [1.38 in.]
30091-07500
Suction cup diam:
ø40 mm [1.57 in.]
30091-08800
Valve lapping
Valve seat cutter Shaft
37591-06400
Valve seat - reface
Width across flats: 32 mm [1.26 in.]
Applicable seat inside/outside diame-
ter: ø45 to 66 [1.77 to 2.60 in.]
Cutter
37591-06430
Valve seat puller 32591-04200 Valve seat - remove
Head bolt plate 37598-08900 Cylinder head bolt - tighten with con-
trolled angle
Maintenance
item
Tool name Part No. Illustration Usage
M12 × 1.25㨺95mm
