Mitsubishi TEJ50AE - 2 Name of each part; Main parts arrangement (TEJ50 AE)

-
2
-
5
2
6
3
7
9
4
8
10
2 Name of each part
Arrangement plan for main parts
3
1
2
4
(To power system)
5
1
Refrigeration unit
4
Cabin controller
2
Control box (high voltage)
5
High voltage cable (orange color)
3
Compressor
• Layout could vary depending on vehicles, etc. Please check before use.
■
TEJ50AE (Single compartment model)
