Mitsubishi XL1XU Service Manual

- 5 -
Power source system 4
NO
YES
NO
YES
YES
NO
YES
When measuring the voltage of the primary power source, use (-) terminal of C903 for GND.
Malfunction of the PCB-MAIN.
Insert or replace them.
The lamp does not light.
Does the lamp light?
NO
Are RE-CN1 and SA-
CN2 lead wires OK?
Remove the PCB-MAIN and
connect the PCB-POWER
TEST.
Pull out the RE-CN1 lead
wire. Turn on only FAN
and POWER on the PCB-
POWER TEST.
Are the pins No. 1
to 4 of the RE
connector 390V?
Malfunction of LAMP
POWER UNIT.
Check the circuit around
Z900, Q901, Q902, IC902
and PC901.
Is the voltage of
the pin No. 8 of
IC901 20V?
Malfunction of PFC circuit.
Check the circuit around IC901
and Q900.
Turn on FAN and LAMP on
the PCB-POWER TEST.
