OPERATION
1) In the main interface, press the MENU key to enter the synergic parameter selection interface;
2) In the synergic parameter selection interface, rotate L Knob to select the required synergic
parameters and press it for confirmation in the interface shown below:
3. Selection and setting of welding parameters:
1) In the main interface, press the MENU key to enter the welding parameter setting interface;
2) In the welding parameter setting interface, rotate L Knob to select the parameter as required and
rotate R Knob to set a value for the parameter. Press L Knob or R Knob for confirmation in the
interface shown below:
Welding parameters
available by rotating L Knob
Welding parameters
available by rotating R Knob
Fig. 2
4. Setting of welding current and voltage
1) Press the ENTER key to enter the welding interface shown below:
