(4) Assemble front end parts of the TIG (5) Lay the outside edge of the Gas Cup on the
torch, fitting a sharpened tungsten suitable work piece with the Tungsten Electrode 1- 2mm
for DC welding. from the work piece. Press and hold the trigger
button on TIG torch to start the gas flow.
(6) With a small movement rotate the Gas (7) Now rotate the Gas Cup in the reverse
Cup forward so that the Tungsten Electrode direction to lift the Tungsten electrode from
touches the work piece. the work piece to create the arc.
(8) Release the trigger to stop the welding.
IMPORTANT! - We strongly recommend that you check for gas leaks prior to operation of
your machine. We recommend that you close the cylinder valve when the machine is not in use.
§4.3.3 DC TIG Welding
