OPERATION
drive roller.
(1) Remove mig torch front end parts. (2) Remove the liner retaining nut.
(3) Carefully pull out and completely remove (4) Carefully unravel the new liner.
the liner.
(5) Carefully feed in the new liner in short forward (6) Fit the liner collet, liner O-ring and
movements down the torch lead all the way to exit liner retaining nut.
the torch neck. Be care-full not to kink the liner.
(6) Push the liner firmly into the torch lead (7) Snip the liner off 3mm past the end
and tighten the liner retaining nut. of the torch neck.
