Chapter Three: Overview Front Panel Components
31
Arrow Keys
The up arrow key [ ] is used to display the next screen in the open menu.
The down arrow key [ ] is used to display the previous screen in the open menu.
Adjust Knob
The adjust knob, which turns clockwise and counterclockwise, is used to select a parameter
value.
Learn Key
This key currently has no function.
Zero Key
This key is used to zero an attached sensor.
Valve Position Control Keys
The three position control keys are used to select the position of the valve.
Set Point Selection Keys
The five set point keys are used to activate one of the internal set points.
