Connecting with Computer
• If your computer is an IBM PC compatible personal computer, then use an optionally available XY-RS-14/34 cable (or equivalent). A
straight cable such as modem cable will not work.
• Make sure the power to the computer and the MODELA is switched off before attempting to connect the cables.
Serial connector
Serial cable
(XY-RS-34 or equivalent)
IBM PC or PC compatible
