2 Check the Included Items
AC adapter: 1 Power cord: 1 Roland software
package: 1
Spindle unit: 1 (*1)
Sensor unit: 1 (*1)
Cap screw M4 x 15: 4
(Two spares)
Tool: 1
(High speed steel)
The shape of the tool may
differ from that below.
Set screw M3 x 3: 2
(One spare)
(*1) Do not discard the included-item box containing the spindle unit and sensor unit.
It is needed to hold the unused unit while Modela is in operation.
(*2) The positioning pin is used when performing double-sided cutting with MODELA.
For detailed information about double-sided cutting, see “Cutting Tips” in the included CD-ROM (refer to "8 Overview of
the Usage Guides").
Front cover: 1 Hexagonal wrench
(size : 3 mm) :1
Hexagonal wrench
(size : 1.5 mm): 1
Positioning pins: 3 (*2)
(diameter 3 mm (0.118 in.),
length 20 mm (0.787 in.))
(One spare)
Double sided tape: 1
Clay: 1 MDX-20/15 User's Manual: 1
The configuration of the
MDX-15 differs, but the
attachment method is the same.
