54
MODELA Player
For information on how to use MODELA Player, see “6 Operation Guide [Cutting Section].”
Virtual MODELA
You can use a tool path created with MODELA Player or 3D Engrave to verify the cutting process and results on-screen before you
perform actual cutting.
You can start this program directly with commands from MODELA Player or 3D Engrave. For more information, see "6 Operation Guide
[Cutting Section] - Sending Cutting Data" or "9 Software Guide - 3D Engrave."
With Virtual MODELA, you can display the cutting process and results in a wide variety of ways.
Animating the Screen During Simulation
Click the . When this button is off, only the shape after simulation is displayed.
Switching the Screen Between Flat and Three-dimensional Views
During Simulation
• Clicking switches from a flat view to a three-dimensional view.
When this button is selected, the view is three-dimensional during and after simulation.
• Clicking
switches from a three-dimensional view to a flat view.
When this button is selected, the display shows a view of the workpiece as seen from above during and after simulation.
Checking the Shape After Simulation
You can use the following buttons only when has been clicked.
Changing the Perspective at the Simulation Screen (Only During 3D View)
You can use the following buttons only when has been clicked to display a 3D view.
• Clicking rotates the object counter-clockwise around the Z axis, in steps of 90 degrees.
• Clicking
rotates the object clockwise around the Z axis, in steps of 90 degrees.
• Rotating
You can use the following buttons only when has been clicked.
