Engineering
26
04/99 AWB 2700-1311 GB
Key to Figure 11:
햲 Main switch
햳 Protection for power supply units
햴 Miniature circuit-breakers
햵 Ground fault monitoring device
햶 Potential equalisation rail
햷 Reference potential for the analog signals
햸 Analog signal input from 0 to 10 V
햹 Analog output
햺 Low-impedance, large contact area connection
between the PS 4-300 and the ground reference
potential via top-hat rail and metal mounting plate
햻 Power supply units grounded
햽 Power supply units not grounded
Maintain a clearance of at least 30 cm
between analog cables and power supply
cables.
Avoid laying the 0 V cable for the analog
signals together with the 0 V cable of the
PS 4-300 and the 0 V cable for the digital
inputs/outputs.
Ensure that analog actuators and encoders
are electrically isolated. If potential isolation is
not sufficient, the manufacturers of the
analog encoder and actuator can provide
suitable filters.
