Topology Configuration
42
04/99 AWB 2700-1311 GB
Overview of the configuration data
The following table contains an overview of the
configuration data for the PS 4-300. The data differs
according to whether the PLC is used as a master or
slave with CPU.
Table 1: Station configuration (basic unit)
(m) = Configuration on master side
(s) = Configuration on slave side
Setting PS 4-300
parameters
The communication conditions between the
individual stations are defined in the parameter
dialog boxes of the Sucosoft S 40 Topology
Configurator.
왘 For this open the Parameters dialog via ‹Edit ➞
Set Parameters› in the topology configurator for
PS 4-300 and set the following parameters:
General settings
(Suconet K master/slave, Transparent mode),
Analog general,
Analog inputs and
Analog output
Master Slave with CPU
(m) (s)
Line 0 1 0
Station 0 1 to 30 0
Module 0 0 0
