Operation
70
04/99 AWB 2700-1311 GB
A warm start can be initiated as follows:
By pressing the “reset” button if the operating
mode selector switch is set to “Run”, provided
that the PLC is currently set to “Ready”;
By switching on the power supply if the operating
mode selector switch is set to “Run”;
Using the programming software on the PC,
provided that the PLC is currently set to “Ready”.
Transferring programs If the user program contains no syntax errors, the
compiler in the programming device (PC) translates it
into code that can be understood and run by the
CPU. You must then load (transfer) the user program
into the RAM of the CPU, where it will be executed by
the microprocessor in the “Run” state.
PC
r PLC
To transfer programs from the PC to the PLC, the
PS 4-300 must be in the “Ready” or “Not Ready”
state, although the operating mode selector switch
on the operating panel can be set to any position.
왘 Transfer the program to the PLC (see the “Test
and Commissioning” section of the
“Sucosoft S 40 user interface” manual,
AWB 2700-1305-GB).
Refer to "Programming via Suconet K" on
page 72 for details of how to transfer the user
program to the PLC via Suconet K.
H1311g.bk Seite 70 Freitag, 4. Juni 1999 1:12 13
