Operation
72
04/99 AWB 2700-1311 GB
Table 11: Start-up behaviour with a memory
module plugged in
Programming via
Suconet K
Several networked stations can be programmed and
test and commissioning functions can be run from a
single PC attached to Suconet K. This method
applies to all stations that are connected to the line
served directly by the master PLC. If one of these
stations (e.g. LE 4-501-BS1) is at the head of another
line, it will not be possible to access the remote
stations attached to this line (dashed line in the
following diagram). Further information on this topic
can be found in the “Sucosoft S 40 user interface”
manual (AWB 2700-1305-GB).
Program Operating
system
Start-up behaviour
Same user
program on PLC
and memory card
Operating system
present/not
present on
memory card
No change
Different user
programs on PLC
and memory card
Operating system
present on
memory card
The operating system and user
program are loaded from the
memory card. The operating
system and user program in
the PLC memory are
overwritten.
Different user
programs on PLC
and memory card
Operating system
not present on
memory card
The program is loaded from the
memory card. Any program in
the PLC memory is
overwritten.
H1311g.bk Seite 72 Freitag, 4. Juni 1999 1:12 13
