Power supply The next few pages contain circuit diagrams of
possible power supply arrangements.
Key to Figure 10:
햲 Main switch
햳 Protection for power supply units
햴 Miniature circuit-breakers
햵 Ground fault monitoring device
햶 Potential equalisation rail
햷 Reference potential for the digital inputs
햸 Power supply for the digital outputs
햹 Low-impedance, large contact area connection
between the PS 4-300 and the ground reference
potential via top-hat rail and metal mounting plate
햺 Unassigned terminal
햻 Input sensors
햽 Power supply for the PS 4-300
햾 Power supply for the digital inputs
햿 Power supply units grounded
헀 Power supply units ungrounded
When using an ungrounded power supply you
must implement an insulation monitoring circuit
(IEC 60 204, Part 1). The 24 V DC supply must be
a safety extra-low voltage acc. to IEC 60 204-1 or
IEC 60 364-4-41 for potentially isolated
operation.
