Moeller PS 4-341-MM1 User Manual

Topology Configuration
54
04/99 AWB 2700-1311 GB
Configuration example The example contains device configurations for
master and slaves with their own CPU. This units are
highlighted in the figure.
Legend for Figure 20
Master: Device A
Slaves with CPU: Devices B, C, D
Slaves without CPU: Devices E, F, G

Remember that slaves with a CPU must be
configured twice. Once for the master and once
for the slave.
