Technical data
85
04/99 AWB 2700-1311 GB
Tec hn ic al da ta
General
Standards EN 61 131-2, EN 50 178
Ambient temperature 0 to 55 °C
Storage temperature –20 °C to 70 °C
Vibration resistance 1 g/0 to 150 Hz
Shock resistance 15 g/11 ms
Vibration Constant 1 g, f = 0 – 150 Hz
EMC
Programming interface RS 232, length of programming
cable < 3 m (10 ft)
Network interface RS 485
Bus Suconet K
Data cable length 600 m/300 m
Transmission speed 187.5 kBaud to 375 kBaud
Operating mode Master/slave
Degree of protection IP 20
Rated insulation voltage U
i
600 V AC
Real-time clock Yes
Accuracy of real-time clock 6.1 min/year (battery-backed)
Battery (life) Typically 5 years
Expansion capacity (local) Up to 5 LEs
Expansion capacity (remote) Up to 30 stations
User program and data memory
(internal)
512 KB
Memory modules (external) 1 MB (backup/recipe memory)
Typical cycle time for 1 K
instructions (bits, bytes)
0.5 ms
Number of inputs (local) 16
Number of outputs (local) 14
Weight Approx. 700 g
Power requirement for CPU
Rated voltage U
e
24 V DC
Admissible range 20.4 to 28.8 V DC
