Moeller PS 4-341-MM1 User Manual

Test/Commissioning/
Diagnostics
86
04/99 AWB 2700-1311 GB
Residual ripple of input voltage < 5 %
Polarity reversal protection Yes
Rated current I
e
Typically 250 + 300 mA per LE
Inrush current and duration 4 A < 5 ms
Power consumption Approx. 6.6 W
Power dissipation (for device as a
whole)
Approx. 6.5 W
Bridging of voltage dips
Duration of dip 10 ms
Repetition rate 1 s
Error display Yes (LEDs)
Protection class 1
Electrically isolated Yes
Terminals Screw terminals
Conductor cross-sections
Flexible with ferrule 0.22 to 2.5 mm
2
Solid 0.22 to 2.5 mm
2
Rated insulation voltage 600 V AC
H1311g.bk Seite 86 Freitag, 4. Juni 1999 1:12 13

Moeller PS 4-341-MM1 Specifications

General

Brand	Moeller
Model	PS 4-341-MM1
Category	Controller
Language	English
