Technical data
87
04/99 AWB 2700-1311 GB
Inputs
Number of inputs 16
Rated voltage U
e
24 V DC
For “0” signal
≤
5 V DC (limit value type 1)
For “1” signal ≥ 15 V DC (limit value type 1)
Maximum ripple < 5 %
Rated current I
e
For “0” signal Typically 6 mA at 24 V DC
Delay time
For “0” to “1” Max. 100 µs
For “1” to “0” Max. 100 µs
Electrical isolation Yes
Electrical isolation between inputs No
Status indication of inputs Yes (LEDs)
Terminals Plug-in screw terminals
Conductor cross-section
Flexible with ferrule 0.22 to 1.5 mm
2
Solid 0.22 to 2.5 mm
2
Incremental encoder
Track A I0.0
Track B I0.1
Track C I0.2
Pulse train frequency 50 kHz
Ref. limit switch I0.3
“High-speed counter” input I0.0/I0.1
Pulse train frequency 50 kHz
Pulse shape Square
Pulse duration 50 %
Edge duration ≤ 3 %
Alarm input I1.0, I1.1
