Starting the PLC with a
memory module plugged in
71
04/99 AWB 2700-1311 GB
PC
r memory module
왘 Switch off the PLC and plug in the memory
module.
왘 Switch on the PLC. The PLC must be set to
“Ready” or “Not Ready”.
왘 Transfer the program from the PC to the memory
module (see the “Test and Commissioning”
section of the “Sucosoft S 40 user interface”
manual, AWB 2700-1305-GB).
Starting the PLC with a
memory module
plugged in
Follow the steps given below if you wish to start the
PS 4-300 with a memory module already plugged in:
왘 Switch off the PLC and plug in the memory
module. The operating mode selector switch can
be set to any position.
왘 Switch on the PLC. Any program in the memory
module will be transferred to the PS 4-300 and
the PLC will run with the set start conditions:

If there is a program in the memory module, any
program in the PLC will be overwritten.
H1311g.bk Seite 71 Freitag, 4. Juni 1999 1:12 13
