Slave Addressing
62
04/99 AWB 2700-1311 GB
Example
You wish to scan the inputs of slaves 1 and 2 in the
diagram below.
Figure 25: Configuration example for scanning the inputs
of remote slaves
The syntax for scanning the inputs can be derived
from the configuration:
EM 4-201-DX2
PS 4-300
Master
EM 4-201-DX2
LE 4-116-DX1
Slave 1
Slave 2.0 ... .7
.7
Line 1 Line 1
