– 9 –
∗
∗∗
∗93 Reports In Armed Period [1,0]
Per Zone (Swinger Suppression) Restrict Unlimited
Restrict Report Pairs: Report Pairs Reports
1 = 1 report pair; 2 = 2 report pairs
NOTE: If restricting report pairs, *70 Alarm Restore Report
Code must be enabled.
Unlimited Reports Enable:
0 = restrict reports to the setting in entry 1
1 = unlimited reports for zones listed in zone list 7; (use
zone list 7 to enter those zones that require unlimited
reporting; these zones ignore the setting in entry 1)
Selection limits the number of alarm/alarm restore message
pairs per zone sent to the CS in an armed period. Swinger
suppression applies to burglary zones only.
DOWNLOAD INFORMATION (
✱
94,
✱
95)
∗
∗∗
∗94 Download Phone No. [18006821690]
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for '
✱
'; #+12 for '#'; #+13 for
a 2-second pause. Do not fill unused spaces. If fewer than
20 digits, exit field by pressing
✱
. To clear entries from field,
press
✱
94
✱
.
UL: Up/downloading via phone line may be performed only if
a technician is at the site.
Up/downloading via the Internet has not been evaluated
by UL.
∗
∗∗
∗95 Ring Count For Downloading [15]
NOTE: Do not enter “0” if using 4286 Phone Module.
0 = Disable Station Initiated Download;
1–14 = number of rings (1–9, # +10 =10, # +11 =11,
# +12 =12, # +13 =13, # +14 =14);
15 = answering machine defeat (# +15 =15).
Refer to the chart below and program accordingly.
phone answer down-
module machine loading Set field ∗
∗∗
∗95 to…
yes no no 1-14 (not 0)
yes yes no greater than rings set on
answer machine (e.g., if ans.
machine is 4 rings, set this
field to 5). This allows access
to the phone module if the
answer machine is off.
yes no yes 1-14 (not 0)
yes yes yes 15 (bypasses answer
machine
†
)
no no no 0
no yes no 0
no no yes 1-14
no yes yes 15
†
NOTE: If “15” is entered to bypass an answering machine, and a
4286 Phone Module is included in the system, you should note
the following:
When calling in from an off-premises phone, the user should make
the initial call, allow 1 or 2 rings only, then hang up, then call again.
The phone module will now seize the line, and 2 long tones sound,
followed by the usual voice prompt for the access code. If this
procedure is not followed, phone module operation will not be
possible.
∗
∗∗
∗96, ∗
∗∗
∗97 Initialize/Reset Defaults
This is a command, not a data field.
∗
∗∗
∗98, *99 Exit Commands
This is a command, not a data field.
PAGER OPTIONS (✱160- ✱172)
The system can send various reports to several pagers (MTV20P =
up to 4; MTV15P = up to 2).
To program pager reporting, do the following:
1. Enter the pager phone number(s), preface characters, and pager
report options in data fields *160 - *171.
2. Enable Pager Delay, if desired, in field *172 (delays alarm
reporting for ALL pagers).
3. Make sure appropriate user open/close pager reports are enabled
(see Security Codes section in User Guide). Users that perform
actions in partition 1 will, if enabled, attempt to report to all
pagers enabled for open/close reporting in partition 1. Users that
perform actions in partition 2 will, if enabled, attempt to report to
all pagers enabled for open/close reporting in partition 2.
4. If using latchkey pager report, define the latchkey report
schedule using Scheduling mode (master code + [#] [6] [4]
then select event type
03
). System must be armed for the
Latchkey report to be sent.
5. If using a function key to manually send a message to a pager,
use *57 Function Key Menu mode to define the key (function
01
).
6. If reporting zone alarms and troubles to a pager, use *81 Zone
List menu mode to assign the zones associated with each pager
(zone lists 9-12
†
).
† MTV15P supports zone lists 9 and 10 only.
∗
∗∗
∗160 Pager 1 Phone No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-
sec pause.
If entering fewer than 20 digits, exit by pressing [∗] + next
field number. To clear entries, press ∗160∗
∗
∗∗
∗161 Pager 1 Characters
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits.
0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
Up to 16 optional characters may be sent as a prefix to the 7-digit
system status code sent to Pager #1 (if used). Phone number in field
*160 must have been entered. If fewer than 16 characters, exit by
pressing [∗] and next field number. To clear entries: press ∗161∗.
The 16 characters may be composed of the following:
PIN number, Subscriber account number,
∗ character, # character, 2-second pause,
†
special character(s) the user may decide to transmit
† Some paging systems require pause(s) before the prefix.
The Pager format for the 7-digit status code is defined as follows:
XXX-YYYY where:
XXX = 3-digit event code: 911 = Alarm, 811 = Trouble, 101 =
Opening (disarm), 102 = Closing (arm AWAY)
YYYY = 4-digit user or zone number (depending on type of event).
The first digit indicates partition (0 = system, 1 = part 1, 2 =
part 2, 3 = common), followed by the 3-digit user or zone
number.
Display Example 1. 911–1004 Indicates an alarm (911) caused
by a fault in zone 4 (0004) in part. 1.
Display Example 2. 102–2005 Indicates the system is reporting
a closing–system arming (102) by User 5 (0005) in partition 2.
∗
∗∗
∗162 Pager 1 Report Options [0,0,0]
P1 P2 common
For each partition, select from the following options:
0 = no reports sent
1 = Opens/closes all users enabled for paging
†
4 = All alarms and troubles
5 = All alarms / troubles, and opens/closes for all users
12 = Alarms / troubles for zones entered in zone list 9
13 = Alarms / troubles for zones entered in zone list 9, and
opens/closes for all users
For each partition, select from the listed options.
† For users enabled for paging. Reports to pager only when
arming (close)/disarming (open) from a keypad using a
security code; auto-arming/disarming, arming with assigned
button, and keyswitch arming do not send pager messages.
To Next Page
