MSSTB-R/C Hardware Manual
400-820-9661
5.3 Recommended Motor
Model Shaft Leads
Length“L”
Holding
Torque
Current Resistance Rotor Inertia Motor Mass
Dielectric
Strength
mm N·m A/Phase Ω/Phase g·cm
2
Kg
AM11HS1008-07
Single Shaft
4
31.0 0.05 1.6 2.5 9.0 0.1
500V AC
1 minute
AM11HS3007-02
Single Shaft
40.0 0.08 1.6 1.7 12.0 0.15
AM11HS5008-01
Single Shaft
51.0 0.12 1.6 3.5 18.0 0.2
AM14HYB401-03
Single Shaft
40.0 0.2 1.0 4.3 20.0 0.21
AM17HD4452-02N
Single Shaft
34.3 0.25 1.8 1.5 38.0 0.23AM17HD4452-01N
Double Shaft
AM17HD4452-E1000D
W/Encoder
AM17HD2438-02N
Single Shaft
39.8 0.4 1.8 1.9 57.0 0.28AM17HD2438-01N
Double Shaft
AM17HD2438-E1000D
W/Encoder
AM17HD6426-06N
Single Shaft
48.3 0.5 1.8 2.3 82.0 0.36AM17HD6426-05N
Double Shaft
AM17HD6426-E1000D
W/Encoder
AM17HDB410-01N
Single Shaft
62.8 0.8 1.6 2.6 123 0.6
AM23HS0421-01
Single Shaft
41.0 0.6 4.5 0.48 135.0 0.42AM23HS0421-02
Double Shaft
AM23HS0421-E1000D
W/Encoder
AM23HS2450-01
Single Shaft
54.0 1.2 4.5 0.63 260.0 0.6AM23HS2450-02
Double Shaft
AM23HS2450-E1000D
W/Encoder
AM23HS3455-01
Single Shaft
76.0 1.8 4.5 0.75 460.0 1.0AM23HS3455-02
Double Shaft
AM23HS3455-E1000D
W/Encoder
AM23HS5412-01
Single Shaft
111.0 3.2 4.5 1.2 750.0 1.5
AM24HS2402-08N
Single Shaft
54.0 1.2 4.5 0.43 450.0 0.83
AM24HS5401-10N
Single Shaft
85.0 2.5 4.5 0.65 900.0 1.4AM24HS5401-24N
Double Shaft
AM24HS5401-E1000D
W/Encoder
AM34HD0404-08
Single Shaft
66.5 3.0 7.0 0.24 1100.0 1.6AM34HD0404-09
Double Shaft
AM34HD0404-E1000D
W/Encoder
AM34HD1404-06
Single Shaft
96.0 5.0 7.0 0.33 1850.0 2.7AM34HD1404-07
Double Shaft
AM34HD1404-E1000D
W/Encoder
AM34HD2403-07
Single Shaft
125.5 7.1 7.0 0.49 2750.0 3.8
AM34HD2403-08
Double Shaft
AM34HD2403-E1000D
W/Encoder
